A single machine of 40ft container side lifter can complete container self-loading and unloading, vehicle-to-vehicle transfer and other operating functions. It can meet the hoisting requirements of containers in different positions, and its characteristics of "fast, flexible, efficient and convenient" have been recognized and recognized by more and more people.
The 40ft container side lifter for sale can realize the loading, unloading and transportation of 20ft or 40ft containers or similar containers through the sliding of the front and rear cranes. It has a wide range of applications and good versatility, greatly expanding the use of the equipment.
The 40ft container side lifter for sale in Dominican is powered by an engine with adjustable speed. The hydraulic oil output by the double pump passes through the confluence valve group, and then is sent to the multi-way valve group of the front and rear side lifters connected in series to drive the respective actuators. It has a wider range of linkage adaptability, which greatly guarantees the stability and reliability of the hoisting process.
The 40ft container side lifter for sale adopts high and low pressure double pumps, and supplies oil to the front and rear cranes after the combined flow through the diverter valve, which can ensure the stability of the speed switching of the side lifter under high and low pressure conditions, and also The output power of the engine can be fully utilized, and the economy is better.
After the container loading and unloading operation of the 40ft container side lifter is completed, by optimizing the movement trajectory of the lifting point and the position of the chain, the automatic storage of the lifting chain during the recovery process of the boom is realized, which greatly improves the comfort of operation and the safety of the whole vehicle.
The container side lifter fromTitan is reasonably matched with the remote wireless control remote. The remote control operation is safe, comfortable and convenient. The remote control panel and handle are people-oriented and conform to the movement trend of the machine, ensuring the smooth operation of the whole machine and accurate control of subtle movements.
Model: 40ft container side lifter for sale in Dominican
Max. lifting capacity: 37Ton
Max.pressure of hydraulic system: 28Mpa
Dimension(L*W*H): 14100*2500*4200mm/7500*2500*4200mm
Axle: 3 axle* 13 ton
Tire: 12R22.5
Suspension: mechanical suspension
KingPin: 3.5 inch bolted type
Braking system: WABCO
Landing gear: JOST
Tow Chain: lgus (imported)
Power source: Power take-off (equipped)
Hydraulic pump: Gear type Casappa Italy
Direction control valves: AMCA Holand
Remote Control: NBB Germany
If you are interested in this 40ft side lifter container for sale, welcome to leave your message!
We will provide more details, quotation, catalog, drawing, videos for you!
