The side lifter truck is composed of semi-trailer and container side loading and unloading crane, which is suitable for the transportation of one or two 20ft or one 40ft container.
The 20ft side lifter truck has two cranes at the front and rear, which are installed on the semi-trailer chassis. The hydraulic power is transmitted through the power take-off of the tractor, and it can slide forward and backward along the chassis. It can be operated wirelessly through the remote control, so as to realize the loading and unloading operations of container transportation. It has the characteristics of compact structure, reliable operation, simple operation and fast operation efficiency.
The crane structure of the side lifter truck for sale is all welded with high-strength steel plates. After the production is completed, the whole vehicle has passed a pressure test to meet the load-bearing requirements, and its load-bearing capacity can reach about 37 tons.
The side lifter truck for sale in Dominican integrates loading, unloading and transporting containers, which is more efficient and reliable. The main accessories are all selected from well-known brands, and the quality is reliable, which makes the operation of side lifter truck safer.
The container lifting operation of the side lifter truck from Titan adopts a wireless remote control system, equipped with an imported wireless remote control, which is easy to operate, sensitive and reliable.
Model: 20 ft side lifter truck for sale in Dominican
Max. lifting capacity: 37Ton
Max.pressure of hydraulic system: 28Mpa
Dimension(L*W*H): 14100*2500*4200mm/7500*2500*4200mm
Axle: 3 axle* 13 ton
Tire: 12R22.5
Suspension: mechanical suspension
KingPin: 3.5 inch bolted type
Braking system: WABCO
Landing gear: JOST
Tow Chain: lgus (imported)
Power source: Power take-off (equipped)
Hydraulic pump: Gear type Casappa Italy
Direction control valves: AMCA Holand
Remote Control: NBB Germany
If you are interested in this 20ft side lifter truck for sale, welcome to leave your message!
We will provide more details, quotation, catalog, drawing, videos for you!
