The 3 axle end dump trailer can self-unload without needing other mechanical equipment, which means that it can complete the unloading and loading of goods in a shorter time, thus improving the overall transportation efficiency.
3 axle end dump trailer for sale can be unloaded by itself, so it is more flexible when transporting goods and can be adapted to various occasions. Whether it is on a construction site, a quarry or other sites, dump trucks can be used for the transportation of goods.
This 3 axle end dump trailer in Dominican has a larger load capacity, which can carry more goods in one shipment, thus reducing the number of shipments, which in turn saves a lot of shipping costs.
The chassis structure design of 3 axle end dump trailer from Titan is reasonable, which can ensure the stability of the cargo during transportation, avoiding problems such as sliding or overturning of the cargo, so as to ensure the safe transportation of the cargo.
The self-unloading design of the 3 axle dump trailer can avoid errors and waste caused by manual operations, and can also reduce the number of transport vehicles and reduce customer operating costs.
3 axle end dump trailer for sale near me has strong applicability and can carry various types of goods, such as stone, soil, construction waste, etc. At the same time, it can also be customized according to specific transportation needs to meet the needs of different industries and customers.
Model: 3 axle end dump trailer for sale in Dominican
Inside dimension: 11280mmx2495mm x3970mm ( depends on final design)
Tare Weight (semi trailer): About 15600kg
Total volume(m³): 30-40m³ or less than 100tons
Side wall thickness: 4 - 6mm
End plate: 8mm
Lifting System: Full set of HYVA lifting cylinder
Axle: 13T/16T, FUWA, BPW etc.
Rim: 8.0-20 or 9.00-20
Tire: 8.25R20/10.00R20/11.00R20/12R22.5
Suspension: Mechanical suspension
Spring leaf: 90(W)mmx13(Thickness)mmx10 layers
Kingpin: JOST brand 2.0 or 3.5inch
Landing gear: Standard 28ton or JOST
If you are interested in this 3 axle end dump trailer for sale, welcome to leave your message!
We will provide more details, quotation, catalog, drawing, videos for you!
